Part Number Prefix: MS3100 thru MS3108
The MIL-DTL-5015 Series I was designed with rear solder contacts and is intermateable with the newer style crimp connectors. This high power connector series provides environmental protection with rear sealing grommets and pin interfacial seal. With 182 layouts available, 5015 Series I offers configurations for power, signal, or a combination of both. This series is used in a variety of applications from mass transit to aerospace systems and has a wide range of shell styles and finishes.
Design Characteristics
- -Medium to heavy weight cylindrical connectors
- -Threaded coupling design
- -MS310( ) series intermateable with existing MIL-DTL-5015 crimp versions
- -Large variety of shell styles and shell sizes from 8 thru 48
- -Rugged connector design that performs well in harsh environments
- -Accommodates high-power and signal contacts in the same layout
- -Rated for 100+ mating cycles, with excellent shock and vibration resistance
Applications
Aerospace
Defense
Industrial
Railway
Franchised Distributor
Benchmark Connector Corp. is an authorized value-added distributor for Spacecraft Component Corp. Every connector order includes a 'Certificate of Conformance' with full traceability back to the manufacturer. Our facility has been government‑audited and approved to assemble a wide variety of military connectors. Benchmark is listed on the U.S. Government’s Qualified Parts List (QPL) for authorized assembly and distribution (Category C) allowing us the flexibility to build exactly what you need.
