MIL-DTL-26482 Series I
MIL-DTL-26482 Series I (Solder)
Part Number Prefix: MS3110 thru MS3116
MIL‑DTL‑26482 Series I connectors are compact, quick‑disconnect circular connectors widely used in military, aerospace, industrial, and transportation systems. They are known for their bayonet‑coupling, reliable environmental sealing, and broad range of insert arrangements. This series is intermateable and interchangeable with other MIL‑DTL‑26482 Series I & II qualified manufacturers.
Design Characteristics:
-Three‑point bayonet coupling Fast, positive mating with audible/tactile feedback—ideal for high‑vibration environments.
-High contact density Supports power, signal, and mixed‑layout configurations in small shell sizes.
-Environmental sealing Interfacial and rear‑grommet seals protect against moisture, dust, and fluids.
-Durable construction available in aluminum, stainless steel, or composite shells with multiple plating options (e.g., cadmium, nickel).
-Wide temperature range Designed for harsh‑environment operation across military‑grade temperature extremes.
Mil-Spec Prefix:
MS3110 Wall Mount, Receptacle
MS3111 Inline Receptacle
MS3112 Box Mount, Receptacle
MS3114 Jam Nut, Receptacle
MS3116 Straight Plug
Materials:
Shell Material and Plating:
Aluminum, Olive Drab
Insert: Thermoplastic & Fluorinated Silicone Elastomer
EMI Spring Fingers: Beryllium Copper
O-Ring: Fluorinated Silicone Elastome
