Part Number Prefix: MS3470 thru MS3476
The MIL-DTL-26482 Standard Series II bayonet connector is miniature, circular with quick disconnect bayonet coupling. It is widely used on applications requiring a general-purpose, miniature cylindrical bayonet connector. It is environmentally sealed and offered in four receptacle-mounting styles including: narrow and wide flange wall-mounting, cable connecting and jam nut mounting receptacles. Designed to eliminate failure modes characteristic of many previous devices, MIL-DTL-26482 Standard connector series stands out as a reliable connector for aerospace environments.
Design Characteristics
- -Medium sized, environmentally resistant connector
- -Three point bayonet system ensures a quick positive connection
- -Utilizes same standard qualified rear-release type plastic tool for contact insertion and removal
- -Five key / keyway eliminates the possibility of mis-mating
- -Contacts are qualified to SAE AS39029 requirements
- -Grommets constructed of a tear resistant elastomer
Applications
Aerospace
Industrial
Marine
Transport
Franchised Distributor
Benchmark Connector Corp. is an authorized value-added distributor for Aero-Electric Connector. Every connector order includes a 'Certificate of Conformance' with full traceability back to the manufacturer. Our facility has been government‑audited and approved to assemble a wide variety of military connectors. Benchmark is listed on the U.S. Government’s Qualified Parts List (QPL) for authorized assembly and distribution (Category C) allowing us the flexibility to build exactly what you need.
