Part Number Prefix: MS27466 thru MS27656
This series was designed for aviation instrumentation applications where space is limited. The MIL-DTL-38999 spec. describes four series of miniature, high density, bayonet, threaded, or breech coupling, circular, environment resistant, electrical connectors using removable crimp or fixed solder contacts, and are capable of operation within a temperature range of -65 to +200 °C. Series I connectors are used where a quick disconnect coupling system is required along with providing characteristics that are suitable for severe wind and moisture problems.
Design Characteristics
- -Small to medium sized, environmentally resistant connector
- -100% Scoop proof design to prevent contacts from being damaged
- -Fast positive coupling by three point bayonet system
- -Five key/keyway design eliminates accidental mis-mating
- -Minimum 500 cycles for a standard plug
- -Grommets constructed of a tear resistant elastomer
Applications
Avionics
Marine
Military
Space
Franchised Distributor
Benchmark Connector Corp. is an authorized value-added distributor for Aero-Electric Connector. Every connector order includes a 'Certificate of Conformance' with full traceability back to the manufacturer. Our facility has been government‑audited and approved to assemble a wide variety of military connectors. Benchmark is listed on the U.S. Government’s Qualified Parts List (QPL) for authorized assembly and distribution (Category C) allowing us the flexibility to build exactly what you need.
