Part Number Prefix: MS27472 thru MS27513
MIL-DTL-38999 Series II features a bayonet coupling mechanism with lower profile design and rear-removable crimp contact retention system. These connectors were designed for military and commercial applications where the requirements are lower profile and lighter weight. A reduction in both size and weight was attained through the use of thinner shell walls and length restrictions. Series II achieves a 39% reduction in outside diameter along with a 40% reduction in weight.
Design Characteristics
- -Light weight, low profile design
- -Fast positive coupling by three point bayonet system
- -Standard rear-release type plastic tool for contact insertion and removal
- -Variety of receptacle shell styles and plating options
- -Minimum 500 cycles for a standard plug
- -Grommets constructed of a tear resistant elastomer
- -Minimum 250 mating cycles for RFI plug
Applications
Aerospace
Defense
Industrial
Marine
Franchised Distributor
Benchmark Connector Corp. is an authorized value-added distributor for Aero-Electric Connector. Every connector order includes a 'Certificate of Conformance' with full traceability back to the manufacturer. Our facility has been government‑audited and approved to assemble a wide variety of military connectors. Benchmark is listed on the U.S. Government’s Qualified Parts List (QPL) for authorized assembly and distribution (Category C) allowing us the flexibility to build exactly what you need.
